MASTERYS BC 15-40 kVA - Ref.: IOMMASBCXX09-EN 01
2.2.2-1 2.2.2-2 2.2.2-3
Remove screws A and B
2.2.2-5
Remove screws A
2.2.2-4
2.2.2-6
Loosen screws B
Remove screws C
2. UNPACKING AND INSTALLATION OF THE UNIT
1
B
2
C
2.2.2-7
Tighten screws B
2.2.2-8
Secure the UPS with feet D
2.2.2-9
Loosen screws B
2
B
1
1
The UPS can be moved.
Place the UPS in the installa-
tion area.
D
D
Secure the UPS with feet D only
when it is in position with the
cable connected.
1
B
2
2
1
3
2
1
A
2
2.2.2. T Models (h 1400 mm)
A
B
