30 EN
MASTERYS BC+ 10-40 kVA - Ref.: IOMMASBCXX0G-EN 00
Function mode Description
The UPS is in maintenance mode
Output breaker / output relays open
Eco mode schedule enabled
An eco mode command has been carried out
A remote stand-by command has been carried out
The energy-saver mode has been enabled
<NOTHING DISPLAYED> Normal mode
Mimic panel
SEGMENT DESCRIPTION
1 INPUT MAINS
2 RECTIFIER ON
3
INVERTER INPUT OR BATTERY
OUTPUT
4 INVERTER OUTPUT
5 UNIT OUTPUT
6 OUTPUT FROM STATIC SWITCH
7 BYPASS INPUT
NOTE!
When in converter mode, 6 and 7 are not shown.
Bar styles identify the energy flow:
• solid: enabled
• dotted: disabled
