Electrical characteristics - Bypass
Rated power (kVA) 60 80 100 120 160
Bypass frequency variation speed 1 Hz/s (settable up to 3 Hz/s)
Bypass rated voltage Nominal output voltage ±20% (selectable)
Bypass rated frequency 50/60 Hz (selectable)
Bypass frequency tolerance ±2% (confi gurable from ±1% to ±10%)
Bypass current overload (A)
10 min 109 145 181 218 290
1 min 130 174 217 261 348
Electrical characteristics - Inverter
Rated power (kVA) 60 80 100 120 160
Rated output voltage (selectable) 380/400/415 V (selectable)
Output voltage tolerance
Static: ±1%
Dynamic: VFI-SS-111 (EN 62040-3 compliant)
Rated output frequency (selectable) 50/60 Hz (selectable)
Output frequency tolerance ±0.01% on mains power failure
Load crest factor ≥ 2.7
Voltage total harmonic distortion THDV < 1% with linear load
Inverter overload (kW)
(1)
10 min 75 100 125 150 200
5 min 79 106 132 158 211
1 min 90 120 150 180 240
Short-circuit inverter current (A)
(when AUX MAINS is not present)
0 to 40 ms 234 312 390 468 624
40 to 100 ms 196 260 326 390 520
Electrical characteristics - Efficiency
Rated power (kVA) 60 80 100 120 160
Double conversion effi ciency up to 96.3%
EcoMode effi ciency 99.4%
Electrical characteristics - Environment
Rated power (kVA) 60 80 100 120 160
Storage temperatures -5 to +50 °C (23 to 122 °F) (15 to 25 °C for better battery life)
Working temperature
0 to +40
(1)
°C (32 to 104 °F) (15 to 25 °C for better battery life)
Up to 50 °C @70% Pn for a limited time
Maximum relative humidity (non-condensing) 95%
Maximum altitude without derating 1000 m (3300 ft)
Degree of protection IP20 (IP21 as option)
Colour RAL 7016
1. The system can supply the full rated load (kW = kVA / PF_out =1) whatever the input voltage within the "voltage tolerance"
range and whatever the temperature within the "working temperature" range.
