socomec MASTERYS GP4 Series User Guide

MASTERYS GP4
From 60 to 160 kVA
99
4. SPECIFICATIONS
4.1 INSTALLATION PARAMETERS
Installation parameters
Rated power (kVA) 60 80 100 120 160
Phase in/out 3/3
Active power kW 60 80 100 120 160
Rated/maximum rectifi er input current
(EN 62040-3)
A 93/110 123/146 154/183 185/219 245/292
Rated bypass input current
(1)
A 96 128 160 191 255
Inverter output current @ 400 V Pn A 87 116 145 174 252
Recommended air fl ow capacity m
3
/h 480 720 840 1080 1440
Acoustic Noise @ 70% Pn dBA 53 55 57
Power dissipation in nominal condi-
tions
(2)
W 2880 3950 4800 5940 7850
kcal/h 2476 3396 4127 5107 6784
BTU/h 9833 13486 16388 20280 26922
Power dissipation (max) in the worst
conditions
(3)
W 3360 4630 5500 6560 8950
kcal/h 2889 3981 4729 5641 7696
BTU/h 11471 15807 18788 22397 30539
Dimensions
Width mm 600
Depth mm 855
Height mm 1400 1400 (1930 optional) 1930
Weight kg 174 186 228 240 350
1. Considering nominal bypass current calculated @ 400 V, considering a continuos overload of 110%.
2. Considering nominal input current (400 V, battery charged) and rated output active power (PF1).
3. Considering maximum input current (low input voltage, battery charged) and rated output active power (PF1).
4.2 ELECTRICAL CHARACTERISTICS
Electrical characteristics - Rectifier Input
Rated power (kVA) 60 80 100 120 160
Rated mains supply voltage 400 V 3ph + N
Voltage tolerance 340 to 480 V (-15 +20%)
Voltage tolerance at derated load up to 240 V @ 70% of nominal active load
Rated frequency 50/60 Hz
Frequency tolerance ±10%
Power factor (at full load and rated voltage) ≥ 0.99
Current Total harmonic distortion (THDi) ≤ 2%
Max inrush current at start-up <In
Power walk-in
(from battery to normal mode)
4 second (settable parameters)
