4
- Ref.: IOMNETRTXX03-XX 02
4
• This instruction sheet completes the Installation and Operating manuals of the UPS
• The battery charger has to be set up depending on the total number and capacity of the NETYS RT external battery modules
(EBM) to be used
• Suggested set up value: ~10÷15% of the capacity (Ah)
WARNING!
To avoid damaging the batteries, due to a high recharging current, the minimum usable battery capacity is 40 Ah
• To size the battery charger correctly please refer to the NETYS RT external battery module (EBM) specifications
• In case of specific battery cabinets used instead of the NETYS RT external battery modules (EBM), it is necessary to use the suit-
able connecting cable, available as an option
• Technical specifications: please refer to the the Installation and Operating manual - see the specifications of the standard UPS
with the same power except for what follows
UPS model NRT-U7000CLA NRT-U11000CLA
Power (UPS protection) 7000 VA
4900 W
11000 VA
8000 W
Battery recharging current 8 A
Dimensions (LxPxH) 440 x 670.5 x 88.7 mm 440 x 623 x 130.6 mm
Weight 16 kg 20.5 kg
UPS wITh POweRFUll bATTeRy chARgeR.
NRT-U7000clA - NRT-U11000clA
lEVEl 1 lEVEl 2 lEVEl 3
BATTERY SETTING BATT LOW ALARM 20%
SHUTDOWN VOLTAGE SD VOLT:168VDC
DISCHARGE TEST no TEST
30 DAYS
60 DAYS
90 DAYS
BATT CABINET NUM NUM: 0
BATTERY AH BATTERY: ... Ah
