socomec STATYS User Manual

STATYS
Jbus / Modbus serial link
OPMSTAJB0810-GB_01 9
ENGLISH
8. 3. StateS tableS: StartIng addreSS 0x0140, 4 wordS
CODE DESCRIPTION BIT ADDRESS Remarks
S00 Source 1 OK 0 0x0140
S01 Source 1 critical 1 0x0140
S02 Source 1 out of tolerance 2 0x0140
S03 Source 1 absent 3 0x0140
S04 PowerPath 1 OK 4 0x0140
S05 5 0x0140
S06 Source 2 OK 6 0x0140
S07 Source 2 critical 7 0x0140
S08 Source 2 out of tolerance 8 0x0140
S09 Source 2 absent 9 0x0140
S10 PowerPath 2 OK 10 0x0140
S11 11 0x0140
S12 Srcs perm. Synchronised 12 0x0140
S13 Sliding Sources 13 0x0140
S14 Srcs perm. Not Synchron. 14 0x0140
S15 Srcs Instant. Synchron. 15 0x0140
S16 S1 is preferred source 0 0x0141
S17 Load on preferred source 1 0x0141
S18 Load on auxiliary source 2 0x0141
S19 Load not supplied 3 0x0141
S20 Load on manual by-pass1 4 0x0141
S21 Load on manual by-pass2 5 0x0141
S22 6 0x0141
S23 Load on S1 7 0x0141
S24 Load on S2 8 0x0141
S25 9 0x0141
S26 Transfer locked ext. 10 0x0141
S27 11 0x0141
S28 Output OK 12 0x0141
S29 Output out of tolerance 13 0x0141
S30 Output absent 14 0x0141
S31 15 0x0141
