SR5 MANUAL
9-STANDARD ADJUSTMENTS OF THE SR5
DRY WET
STUB AXLE HEIGHT
FRONT TRACKING WIDTH
REAR TRACKING WIDTH
REAR AXLE POSITION /
TIGHTENING OF THE
CENTRAL BEARING
POSITION OF MASSES
POSITION OF EXCENTRICS
POSITION OF STEERING
TIE RODS ENDS
DOUBLE LATERAL CRADDLE /
REAR TORSION BAR
REMOVE the double lateral
craddle.
REMOVE the torsion bar.
PLACE the double lateral
craddle.
PLACE the torsion bar
horizontally.
4mm 4mm+4mm
4mm +2mm
2mm
3 rings inside
Short hub 60mm
All rings inside
Long hub 80mm
1360 to 1370mm
1400mm
TOP
Loosened central bearing
TOP
Tightened central bearing
2
1
FOR TYRE PRESSURES, REFER TO TABLE PAGE 29
A-2
OR
B
-
3
B-3
3
3
FWD
TOP
rd
Mark - Forward
BOTTOM
Mark – Inwa
Eccentrics 4°
TOP
BOTTOM
Eccentrics 1°
FWD
Mark - Backward
Mark - Forward
- 17 -
