SR5 MANUAL
13- TYRES
13-1 CHANGING THE TYRES
:
Sens de roulage
2
3
1. Lay the kart on a trolley.
2. Lay the wheel on the tire removal tool
(OU942.002)
3. Once the edges of the tire are separated
from the rim on both sides, remove the tire
with the tool (2).
4. Put grease (3) (LU823.003) on the edges of
the new tire.
5. Install the tire on the rim; mind the
direction of rotation.
6. Inflate to let the tire get its position on the
rim.
7. Adjust the pressure according to table next
page, with the manometer (OU943.002).
9 Check the direction of rotation on the sides of the tire.
9 Never inflate above 4 bars: there is a risk of severe injury due to potential failure of
the rim.
- 28 -
