identification AC;
Step 4 As shown in figure 4-14, Tighten the waterproof lock nut, install the
waterproof cover and tighten it.
Figure 4-14
4.5. RS485,CT,inverter logic interface connection
The communication interface location of the SOFAR 7.5KTLM is shown in
the figure below.
Figure 4-17
Table 4-3 Recommended communication cable size are shown below,The
wiring methods are the same for RS485 and CT,this part describes their wiring
methods and logic interface wiring method.
