SOFAR 7.5KTLM User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd
through the cable gland and waterproof cover, according to Table4-4,connect the
wires as per the labels, and secure the wire using a slotted screwdriver.as shown in
the figure below:
Table 4-4 Function description of the communication terminals
Figure 4-20
The logic interface pin definitions and circuit connections are as follows:
The function of logical interface needs to be set on the display screen, please
refer to the operation steps in section 6.3 .
