2
Rear panel
1pcs
3
PV+ input terminal
2pcs
4
PV- input terminal
2pcs
5
Metal terminals secured
to PV+ input power
cables
2pcs
6
Metal terminals secured
to PV- input power
cables
2pcs
7
BAT- input terminal
1pcs
8
BAT+input terminal
1pcs
9
M6 Hexagon screws
3pcs
10
M8*80 Expansion bolts used
to secure the wall-mount
bracket to the wall
4pcs
11
AC Grid connector
1pcs
12
Load Output connector
1pcs
13
Link port connector
1pcs
14
8 pin terminal
Matching terminal resistance
（parallel system）
1pcs
