7. Technical Data
Model
HYD3000-ES
HYD4000-ES
HYD5000-ES
HYD6000-ES
Battery Parameters
Battery Type
Lead-acid, Lithium-ion
Nominal battery voltage
48V
Battery voltage range
42 - 58V
Recommended battery capacity
200Ah (100 – 500 Ah optional)
Recommended storage capacity
9.6 kWh
Max charge current
60A
Charge current range
0 – 65A programmable
Charge curve
3 - stage adaptive with maintenance
Max discharge current
0 – 70A programmable
Battery protection
Over voltage protection / Over current protection / Over
temperature protection
Depth of discharge
Lithium: 0 – 80% DOD adjustable
Lead acid: 0 – 50% DOD adjustable
PV parameters
The max input power
3500W
4400W
5500W
6600W
Max DC power for single MPPT
2000W
(160V-520V)
2600W
(200V-520V)
3000W
(250V-520V)
3500W
(300V-520V)
The max DC input voltage
600V
Start-up DC voltage
120V
Nominal DC Voltage
360V
MPPT operating voltage range
90-580V
Full load DC voltage range
160V-520V
200V-520V
250V-520V
300V-520V
MPPT number
2
The max DC input current
12A/12A
The max DC input short current
15A/15A
AC parameters
Max output power
3000W
4000W
5000W
6000W
Max output current
13.7A
18.2A
22.8A
27.3A
Nominal grid voltage & frequency
230V, 47 – 53Hz or 57 – 63Hz
AC voltage range
150 – 275V (according to local authority requirements)
THDi
<3%
