INSTALLATION
30 HYD 5K...20KTL-3PH
No.
Description
Quantity
01
Inverter HYD 5K ... 20KTL-3PH
1
02
Wall bracket
1
03
PV+ input terminal
4
04
PV- input terminal
4
05
MC4 connector contact PV+
4
06
MC4 connector contact PV-
4
07
BAT input connector
2
08
BAT+ connector contact
2
09
BAT- connector contact
2
10
Secured metal clamps
at BAT+ power input cable
2
11
M6 hexagon screw
2
12
M8*80 expansion screws (wall bracket)
4
13
AC grid connection
1
14
AC load connection
1
15
Link port connection
1
