COMMISSIONING THE INVERTER
HYD 5K...20KTL-3PH 87
3) Safety parameter
import
You need to read the Country
Code setting from a USB drive.
Alternatively, the mobile App can
be used for this setting, if you are
logged in as a validated installer
4) Set the input channel
With the Input Channel
Configuration you define if PV and
/ or batteries are connected and
in what configuration. If aa Input
Channels is not used, select (not
used)
Input Channel 1
(MPPT1)
if PV strings are connected to MPPT1,
select “MPPT1”
Input Channel 2
(MPPT2)
if PV strings are connected to MPPT2
independently, select “MPPT2”
If PV strings are connected to MPPT2
in parallel to MPPT1, select “MPPT1”
Input Channel 3 (BAT1)
If a battery is connected to BAT1 input,
select “BAT1”, otherwise “disable”
Input Channel 4 (BAT2)
if a second battery is connected to
BAT2 independently, select “BAT2”
If one battery is connected in parallel
to BAT1 and BAT2, select “BAT1”
5) Set battery parameters
Default values can be set
according to the input channel
configuration in Menu Advanced
Settings – Battery Parameter:
Select Battery Type
