ELECTRICAL CONNECTIONS
SOFAR 3 ... 6KTLM-G3 45
3. Connect the AC output cable in accordance with the following
requirements and tighten the terminal using the Allen key (type 1)
or the Phillips head screwdriver (type II).
Connection
Cable
PE
Earthing cable (yellow-green)
L
Phase (brown)
N
Neutral conductor (blue)
4. Assemble the connector housing and screw the cable gland tight.
5. Connect the AC connector to the AC connection of the inverter by
turning it clockwise until it locks into place.
