Power
5
Batteries
Use NiMH (Nickel Metal Hydride) batteries - AA size. Minimum 1800 milli-amp
hours.
Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
iSTAR Pro batteries are packaged separately and should be installed in the battery
backup sockets at the bottom of the GCM.
The unit is stored and shipped with the batteries disconnected so they will not be
drained while in storage. Connect the batteries as shown in the GCM diagram that
follows. If the batteries are installed with the power off, the reset switch (S5) must be
pressed after power is applied.
It is acceptable to install the batteries with the power on. However, if the batteries are
installed with the power on, you do not need to press the reset switch.
NOTE
The batteries provide power to retain the volatile memory (clearances, activity,
etc.) data in the event of a power failure. The batteries do not supply enough
power for iSTAR Pro normal operations.
