5. APPLICATION DO 160C, SECTION 22
5.1 CATEGORIES AND TEST LEVEL TABLE
TEST LEVEL
CATEGORY Long Wave
70 uS Direct Injection
Short Wave
6.4 uS Probe Injection
1 MHz & 10 MHz
Sinusoidal wave
Vp Ip Vp Ip Vp Ip
J 125 25 125 25 250 10
K 300 60 300 60 600 24
L 750 150 750 150 1500 60
M 1600 320 1600 320 3200 128
Vp= Peak open circuit Voltage (V)
Ip= Peak test limit Current (A)
5.2 Calibration Setup (100 ohm loop)
Equipment used
Solar Model 9354-2 Transient Pulse Generator.
Type 9357-1 Calibration Fixture.
Type 9335-2 Multiple Coupling Injection Probe.
Type 9841-1 High voltage 50 ohm termination.
Type 9410-1 High voltage Attenuator 50/50.
For frequencies above 1 MHz.
Type 9125-1 Calibration Fixture.
Type 9142-1N Injection Probe.
10 KHz Damped
sinusoidal into
Type 9335-2 port 2
% of Amplitude to
active
I max 70 %
I max 0.1 amp = 5 volts 50 ohm coaxial
cable ~ 6 ft
100 KHz
into Type 9335-2 port 2
% of Amplitude to
active
I max 70 %
I max 1 amps = 50 volts 50 ohm coaxial
cable ~ 6 ft
1 MHz
into Type 9335-2 port 2
% of Amplitude to
active
I max 60 %
I max 10 amps = 500 volts 50 ohm coaxial
cable ~ 6 ft
