NOTE:
Output parameters vary between the duration or frequency of the selected waveforms, and will be
effected by the coupling method and the coupling device employed.
6 High Energy Outputs - All output BNC connectors and pairs of binding posts provide
for connection of each pulse to the coupling device for series cable injection of up to 3200
volts peak unloaded and 1600 amperes peak loaded. The mating BNC connector and
banana plugs are designed and insulated for an open circuit voltage of greater than 4500
volts peak and (2) short circuit currents in excess of 2250 amperes peak. The outer shell
of the BNC output connector and the black jack of each output terminal pair are
grounded to the front panel and chassis ground. The generator output ground can be
isolated through a Solar Type 9335-2 coupling device, and for 6.4 uS a audio isolation
transformer Solar Type 6220-4.
7 External Impedance: Because of the generator's wide range of parameters and various
calibration techniques specified by the different requirements, each output or waveform
has been designed to meet the more stringent of these requirements, provided the
appropriate EXTERNAL impedance network is used (see application NOTES)
CAUTION!
TURN SELECTOR SWITCH TO 120uS POSITION than turn AMPLITUDE KNOB TO ZERO, AND
PULSE THE 120 uS TO DISCHARGE ALL CAPACITORS.
