Solar Electronics 9354-2 - SPECIFICATIONS (All Verification Testing Should be Done at 50% to Prolong Life); Damped Sinusoid; Double Exponential; Power Requirements

Solar Electronics Company
3. SPECIFICATIONS
DAMPED SINUSOID
10 KHz
Open Circuit Voltage ................................................................................................................................ 30.0 V
Source Impedance................................................................................................................................... < 0.25 Ω
100 KHz
Open Circuit Voltage ............................................................................................................................... 300.0 V
Source Impedance..................................................................................................................................... < 3.8 Ω
1 MHz
Open Circuit Voltage ............................................................................................................................ 3200.0 V
Source Impedance................................................................................................................................... <28.0 Ω
10 MHz
Open Circuit Voltage ............................................................................................................................ 3200.0 V
Source Impedance................................................................................................................................... <39.0 Ω
30 MHz
Open Circuit Voltage ............................................................................................................................ 1500.0 V
Source Impedance................................................................................................................................... <50.0 Ω
100 MHz
Open Circuit Voltage .............................................................................................................................. 600.0 V
Source Impedance................................................................................................................................... <50.0 Ω
DOUBLE EXPONENTIAL
6.4 μS
Rise Time.................................................................................................................................................... 100 nS
Open Circuit Voltage ............................................................................................................................... 1600 V
Source Impedance..................................................................................................................................... < 2.0 Ω
70.0 μS
Rise Time..................................................................................................................................................... 6.4 μS
Open Circuit Voltage ............................................................................................................................... 1600 V
Source Impedance..................................................................................................................................... < 2.0 Ω
120.0 μS
Rise Time...................................................................................................................................................... 40 μS
Open Circuit Voltage ................................................................................................................................. 750 V
Source Impedance........................................................................................................................................ 1.0 Ω
POWER REQUIREMENTS
Power Source ....................................................................... 115 V unit: 60 Hz, or 230 V unit: 50 Hz
Power Consumption .............................................................................................................. 50 Watts
Power Line Fuses ................... 115 V unit: 2 @ 3A Slow-Blow, or 230 V unit: 2 @ 1.5A Slow-Blow
PHYSICAL CHARACTERISTICS
Net Weight .................................................................................................................... 55 Lbs. (25 Kg)
Shipping Weight ........................................................................................................ 58 Lbs. (26.3 Kg)
Height ....................................................................................................................... 9.12 In. (222 mm)
Width ...................................................................................................................... 17.12 In. (435 mm)
Depth ....................................................................................................................... 13.50 In. (343 mm)
