Solar Electronics Company
4.APPLICATION
1 The six damped sinusoidal waveforms meet the requirements of MIL-STD-461E and
MIL-STD-461D, test method CS116, when applied in accordance with the corresponding
test method of MIL-STD-461E and MIL-STD-462D. These same waveforms are
applicable to the requirements of MIL-STD-461C, CS10 & CS11 when applied with the
test method of MIL-STD-462, Notice 5.
2 Extended limits: Two of the six damped sinusoidal waveforms (1 MHz and 10 MHz)
have their limits extended to an open circuit voltage of 3200 volts peak to meet the
requirements of DO-160D, Section 22, Table 22-2,.
3 Double exponential: The double exponential pulses were specifically designed to meet
the requirements of DO-160C, Section 22, (See table below).
