Solar Electronics 9354-2 - Waveform 5 A

Solar Electronics Company
volt double exponential waveforms.
SOLUTION: By using the 1 M input and a 50 ohm termination at the scope gives you the 50 ohm input
required by the MIL-STD-461. This allows you to have 10 volts per division X 100 will give you 1000 volts
per division when using the type 9454-1 or the 9410-1 40 dB Attenuator.
NOTE
As specified in para 22-2 of RTCA DO-160D category specification.
Category J is intended for equipment and interconnect wiring that will be installed in a partially
protected environment such as an enclosed avionics bay in an all-metallic aircraft.
Category K is intended for equipment and interconnect wiring that will be installed in a
moderate environment such as the more electromagnetically open area (e.g., cockpit) of an
aircraft composed principally of metal.
Category L & M is intended for equipment and interconnect wiring that will be installed in
severe electromagnetic environments. Such levels might be found in all-composite aircraft or
other exposed area in metallic aircraft.
Category X No test required.
