Solar Electronics 9354-2 - Page 3

Solar Electronics Company
FEATURES
■
Panel mounted digital Voltmeter displays reference open circuit discharge
voltage.
■ Automatic or manual trigger for damped sinusoidal pulses. Manual
triggering for double exponential pulses.
■ Variable peak output voltage. VOLTMETER DISPLAY IS A REFERENCE
FOR A OPEN CIRCUIT VOLTAGE.
■ An independent circuit for each waveform improves reliability, simplifies
maintenance, and allows for customized waveforms and output
impedances.
■ Solid state switching and RC networks across coils, switches, and relay
contacts to reduce arcing, eliminate contact bounce, and increase
component life.
SOLAR ELECTRONICS HOLLYWOOD CALIF. 90038
MODEL 9354-2 TRANSIENT GENERATOR
3200.00
WAVEFORM
10 kHz
100 kHz
1MHz
10 MHz30 MHz100 MHz
6.4 uS
50%
62%
75%
87%
100%
0%
12%
25%
37%
AMPLITUDE
AUTO/MANUAL
TRIGGER
MODE
70 uS
6.4 uS
POWER
OFF ON
DISCHARGE VOLTAGE
120 uS
70 uS
120 uS
