EV ChargerWeb interface
Configuration manual V1.00
16
© SolarEdge Technologies
The actual size of the web interface may differ depending on the device vari-
ant.
4.1 Main menu
The main menu is divided into the following areas:
● Status
● Charging Sessions
● RFID Cards
● Charging Network
● System
● Configuration
4.1.1 Status
This page is divided into the following sections:
Overview
Here, basic information about all charging stations in the charging network is
displayed (such as serial number, IP address, operating state, etc.).
When the respective IP address is clicked, a new browser window displays
information about the charging, such as total energy, energy of a charging
session, power, voltage, current, status and event log. The scope of the dis-
played information is variant-dependent.
An "Actions" button is located next to each listed charging station. When the
button is clicked, the following functions are available:
Start Charging
Authorizes a charging session without an RFID card having to
be held before the sensor. This function is only available with
the authorization function enabled.
Stop Charging Ends the active charging session.
Restart Restarts the charging station.
Unlock
Unlocks the charging plug on the charging station (not for the
vehicle). For an active charging session, the charging session is
ended first and then the charging plug is unlocked.
Network Connection
Here, information about the network interfaces (LAN, mobile communica-
tions, WLAN and WLAN Access Point) of the master charging station is dis-
played.
Backend
Information about the OCPP backend (such as connection status and ad-
dress) is displayed here.
