8 MAN-01-00786-1.3
Connecting Cables
6
CAUTION! Remove plates
from unit before drilling holes
Max conduit
size 2”
1.9 lb*ft
Max conduit
size 2.5”
CAUTION! Donot
block Airflow
Boundary for single conduit
entry. Max conduit size 3”
Connect cables
according to labels
2
Align pin grooves in
connector with pin
guides in socket
1
