Connect input from Module
Connect output to String
5
6
MAN-01-00786-1.3 3
2:1 series connection
Use a dual input optimizer (P800p)
for parallel connection of two PVs
or use a branch cable to connect
two PVs to a single input optimizer.
Installing the Power Optimizers
1
1 2 3 4 5 6
