WARNING!
For inverters with manual Rapid Shutdown (PVRSS) functionality - Upon
PVRSS, the internal circuitry remains up, therefore the inverter cover
must be opened only after shutting off the inverter ON/OFF switch. This
disables the DC voltage inside the inverter. Wait five minutes before
opening the cover. Otherwise, there is a risk of electric shock from
energy stored in the capacitors.
LCD panel: displays inverter information and configuration parameters
LCD LEDs: Three LEDs indicate the following inverter statuses:
Color Description Functionality
Green Power production
On - The inverter is producing power.
Blinking - Standby mode. The inverter is in
Standby mode until its working voltage is
reached. The inverter then enters Production
mode and produces power.
Off - The inverter is not producing power. This
may be during Night mode, when the inverter
ON/OFF switch is OFF or when an error occurs.
Yellow
Module
communication and
inverter shutdown
Blinking:
Monitoring information is being received
from a power optimizer.
The inverter is being shut down.
Red Fault
On - There is an error. Refer to
Errors and
Troubleshooting
on page 80 for more
information.
Blinking - The inverter is being shut down.
All LEDs turn on while the inverter is being configured.
Chapter 3: Installing the Inverter 25
Three Phase System Installation Guide MAN-01-00057-4.1
