RS485
RS485 is used for the connection of multiple SolarEdge devices on the same bus in a
master-slave configuration. RS485 can also be used as an interface to external devices,
such as meters and third party data loggers.
RS485-1: Enables the connection of multiple devices (inverters/Commercial
Gateway)over the same bus, such that connecting only one device to the
Internet is sufficient to provide communication services for all the devices
on the bus.
RS485 Plug-in: Purchased separately, the RS485 Plug-in
provides an additional RS485 port (referred to as RS485-E) for
the inverter for enhanced communications. The plug-in is a 3
pin terminal block which is installed on the communication
board. This kit is provided with an installation guide, which
should be reviewed prior to connection see,
https://www.solaredge.com/sites/default/files/RS485_expansion_kit_installation_
guide.pdf
For connection instructions refer to
Creating an RS485 Bus Connection
on page 74
For connection instructions refer to .
Wi-Fi
This communication option enables using a Wi-Fi connection for
connecting to the monitoring platform.
The Wi-Fi option requires a Wi-Fi Plug-in and an external antenna,
available from SolarEdge in a kit, which can be purchased separately and
assembled during system installation. The Wi-Fi Plug-in kit is provided
with a user manual, which should be reviewed prior to connection. Refer to
http://www.solaredge.com/sites/default/files/se_wifi_communication_solution_installation_
guide.pdf
Cellular (GSM, CDMA)
Chapter 7: Setting Up Communication 67
Three Phase System Installation Guide MAN-01-00057-4.1
