6 Troubleshooting
6.1 Troubleshooting
Check the previous indicators to determine the status of the T-BATsystem.
A warning state is triggered when conditions such as voltage or temperature
exceed the design limitations. T-BAT system's BMSperiodically reports its
operating state to the inverter.
When the T-BAT system falls outside the prescribed limits, it entersinto a
warning state.
Use the monitoring software on the inverter to identify what caused the warning.
The possible error messages are as follows:
6. Troubleshooting
When a warning is reported, the inverter immediately stops its operation.
6. Troubleshooting
Check if the communication
cable between BMS and
inverter is correctly and well
connected.
1. Move the DIP switch to the
correct position;
2. Check if the communication
cable between battery
modules is correctly and well
connected.
BMS_Internal_Err
1) DIP switch on the
wrong position
2) The communication
between battery
modules is interrupted.
1) Move the DIP switch to the
correct position
2) Check if the communication
cable between thebattery
modules is correctly and
properly connected.
BMS_OverVoltage Battery over voltage
BMS_LowerVoltage
Battery under voltage
BMS_ChargeOCP
Battery charge over
current protection
Error Messages Description Troubleshooting
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
BMS_Ver_Unmatch
The version of
BMS isunmatched
Contact your distributor or
SolaX directly for servicing.
BMS_DishargeOCP
Battery discharge over
current protection
Contact your distributor or
SolaX directly for servicing.
1) Ensure the power cable is
correctly and properly connected to
the power connector (XPLUG) of
theBMS
2) If the first step still does not
work, contact your distributor or
SolaX directly.
BMS_TemHigh
Battery over
temperature
BMS_TemLow
Battery under
temperature
BMS_Hardware_Protect
Battery hardware
under protection
BMS_Insulation_Fault
Battery insulation
fault
BMS_VoltSensor_Fault
Battery voltage
sensor fault
BMS_TempSensor_Fault
Battery
temperature
sensor fault
BMS_CurrSensor_Fault
Battery current
sensor fault
BMS_Relay_Fault Battery relay fault
BMS_Type_Unmatch
The type of BMS
isunmatched
Warning Messages Description Troubleshooting
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Contact your distributor or
SolaX directly for servicing.
Wait until the temperature of the
cells returns to the normal state.
Wait until the temperature of the
cells returns to the normal state.
