3.2 Basic Features
3.2.1 Features
The T-BAT SYS-HV is one of the most advanced energy storage systems on
the market today, incorporating state-of-the-art technology, high reliability, and
convenient control features shown as below:
Ÿ 90% DOD
Ÿ
Ÿ
95% Battery Roundtrip Efficiency
Ÿ
Cycle Life > 6000 Cycles
Ÿ
Secondary Protection by Hardware
Ÿ
IP65 Protection Level
Ÿ
Safety & Reliability
Ÿ
Small Occupied Area
Floor or Wall Mounting
3.2.2 Certifications
3. Product Introduction
BAT system safety
UN number
Hazardous materials classification
UN transportation testing requirements
International protection marking
CE, RCM, IEC 62619
UN 3480
Class 9
UN 38.3
IP 65
3. Product Introduction
3.3 Specifications
3.3.1 T-BAT SYS-HV Configuration List
ModelNo.
1
2
3
4
T-BAT H 3.0
T-BAT H 6.0
T-BAT H 9.0
T-BAT H 12.0
BMS
MC0600×1
Battery Module
HV10230×1
Energy(kWh)
3.1
6.1
9.2
12.3
Voltage (V)
90-116
180-232
270-348
360-464
MC0600×1
MC0600×1
MC0600×1
HV10230×2
HV10230×3
HV10230×4
3.3.2 Performance
Q.+ BAT-G1
Nominal Voltage (Vdc)
Operating Voltage (Vdc)
Nominal Capacity (Ah)
Max. Charge/Discharge Current (A)
Recommend Charge/Discharge Current (A)
Standard Power (kW)
Max. Power (kW)
90-116
30
30
25
2.55
3.1
307.2
270-348
30
30
25
7.65
9.2
Battery Roundtrip Effciency(0.2C,25°C/77°F)
Expected Lifetime(25°C/77°F)
Cycle Life90% DOD,(25°C/77°F)
Available Charge/Discharge Temperature Range
Storage Temperature
Ingress Protection
95%
10 years
6000 cycles
IP65
Model
-30°C--50°C(with heating function)
-20°C--50°C(3 months)
0°C--40°C(12 months)
**
Test conditions: 100% DOD, 0.2C charge & discharge @+25°C
Discharging: 0-5°C and 45-50°Cwill be rating;
90% DOD; System usable energy may vary with inverter different setting
Charging: 0-15°C and 40-50°C will be rating
1
2
1
2
3
3
102.4
Nominal Energy (kWh)
3.1 9.2
Usable Energy (kWh)
2.8 8.3
MC0600+
HV10230×2
MC0600+
HV10230×3
MC0600+
HV10230×1
MC0600+
HV10230×4
180-232
30
30
25
5.1
6.1
204.8
6.1
5.5
360-464
30
30
25
10.2
12.3
409.6
12.3
11.0
-10°C--50°C(no heating function)
4
5
4
5
The battery can be discharged and charged at -30-0°C
The battery can be discharged and only can not be charged at -10-0°C
1
