SolaX Power T-BAT-SYS-HV-R2.5 User Manual

3. Product Introduction
Note:
① Test conditions: 100% DOD, 0.2C charge & discharge @+ 77°F/25°C.
② 90% DOD; System usable energy may vary with inverter different setting.
③ Discharge: In case of the battery cell's temperature range of -4°F~14°F/-
20°C~10°C and 113°F~122°F/45°C ~50°C, the discharge current will be reduced;
Charge: In case of the battery cell's temperature range of 32°F~77°F/0°C~25°C
and 113°F~122°F/45°C ~50°C, the charge current will be reduced. Product charge
or discharge power depends on the actual temperature of the battery pack.
④ The battery can only be discharged and cannot be charged at -4°F~32°F/-
20°C~0°C.
⑤ In case of a rated current of 30 A, the wire size of 10 AWG for ground wire is
recommended; in case of a rated current of 45 A, the wire size of 8 AWG for
ground wire is recommended. Note: The above-mentioned ground wires shall be
prepared by the user self.
⑥ In the allowable range, the relative humidity range should be between 0% and
90% RH.
14
15
3. Product Introduction
3.3.2 T-BAT-SYS-HV-R3.6
Continued on the next page
■ Performance
■ Configuration List
Module T-BAT H R20 T-BAT H R22.5 T-BAT H R25 T-BAT H R27.5 T-BAT H R30 T-BAT H R32.5
Nominal Voltage (Vdc) 409.6 460.8 512 563.2 614.4 665.6
Operating Voltage (Vdc) 360-465 405-522 450-580 495-636 540-695 585-750
Nominal Capacity (Ah) ① 50 50 50 50 50 50
Nominal Energy (kWh) ① 20.48 23.04 25.6 28.16 30.72 33.28
Usable Energy 90% DOD (kWh) ②
18.4 20.7 23.0 25.3 27.6 30
Max. Charge/Discharge Current
(A) ③
45 45 45 45 45 45
Recommend Charge/Discharge
Current (A) ⑤
30 30 30 30 30 30
Standard Power (kW) 10.24 11.52 12.8 14.08 15.36 16.64
Max. Power (kW) 18.4 20.7 23 25.3 27.6 30
Short-circuit Current (A) 2500 2500 2500 2500 2500 2500
Battery Roundtrip Effciency (0.2C,
25°C/77°F)
Expected Lifetime (25°C/77°F)
Cycle Life 90% DOD (25°C/77°F)
Charge Temperature
Discharge Temperature
Storage Temperature
Ingress Protection
Protection Class
I
-4°F~122°F/-20°C~50°C (3 months)
50°F~104°F/0°C~40°C (1 year)
IP20
95%
10 Years
6000 Cycles
32°F~122°F/0°C~50°C ④
-4°F~122°F/-20°C~50°C ④
No. Module BMS Battery Module
Nominal
Energy (kWh)
Operating
Voltage (Vdc)
1 T-BAT H R7.2 TBMS-MCR0800 × 1 TP-HR36 × 2 7.37 90-116
2 T-BAT H R10.8 TBMS-MCR0800 × 1 TP-HR36 × 3 11.06 135-174
3 T-BAT H R14.4 TBMS-MCR0800 × 1 TP-HR36 × 4 14.75 180-232
4 T-BAT H R18.0 TBMS-MCR0800 × 1 TP-HR36 × 5 18.43 225-290
5 T-BAT H R21.6 TBMS-MCR0800 × 1 TP-HR36 × 6 22.12 270-349
6 T-BAT H R25.2 TBMS-MCR0800 × 1 TP-HR36 × 7 25.8 315-406
7 T-BAT H R28.8 TBMS-MCR0800 × 1 TP-HR36 × 8 29.49 360-465
8 T-BAT H R32.4 TBMS-MCR0800 × 1 TP-HR36 × 9 33.18 405-522
9 T-BAT H R36 TBMS-MCR0800 × 1 TP-HR36 × 10 36.86 450-580
10 T-BAT H R39.6 TBMS-MCR0800 × 1 TP-HR36 × 11 40.55 495-636
11 T-BAT H R43.2 TBMS-MCR0800 × 1 TP-HR36 × 12 44.24 540-695
12 T-BAT H R46.8 TBMS-MCR0800 × 1 TP-HR36 × 13 47.92 585-750
Module
T-BAT H R7.2 T-BAT H R10.8 T-BAT H R14.4 T-BAT H R18.0 T-BAT H R21.6 T-BAT H R25.2
Nominal Voltage (Vdc) 102.4 153.6 204.8 256 307.2 358.4
Operating Voltage (Vdc) 90-116 135-174 180-232 225-290 270-349 315-406
Nominal Capacity (Ah) ①
72 72 72 72 72 72
Nominal Energy (kWh) ①
5.12 7.68 10.24 12.8 15.36 17.92
Usable Energy 90% DOD (kWh)
②
6.6 10.0 13.3 16.6 19.9 23.2
Max. Charge/Discharge Current
(A) ③
50 50 50 50 50 50
Recommend Charge/Discharge
Current (A) ⑤
35 35 35 35 35 35
Standard Power (kW) 3.58 5.38 7.17 8.96 10.75 12.54
Max. Power (kW) 5.12 7.68 10.24 12.8 15.36 17.92
Short-circuit Current (A) 2500 2500 2500 2500 2500 2500
Battery Roundtrip Effciency
(0.2C, 25°C/77°F)
Expected Lifetime (25°C/77°F)
Cycle Life 90% DOD (25°C/77°
F)
Charge Temperature
Discharge Temperature
Storage Temperature
Ingress Protection
Protection Class
I
-4°F~122°F/-20°C~50°C (3 months)
50°F~104°F/10°C~40°C (1 year)
IP20
95%
10 Years
6000 Cycles
32°F~122°F/0°C~50°C ④
-4°F~122°F/-20°C~50°C ④

SolaX Power T-BAT-SYS-HV-R2.5 Specifications

General

Brand	SolaX Power
Model	T-BAT-SYS-HV-R2.5
Category	Battery Pack
Language	English
