Solax X3-Hybrid User Manual

8. Setting
8.1 Control Panel
A
B
C
D
E F G H
Menu
Grid
Solar
Charger
EPS
Load
Status
History
Setting
System Switch
About
Inverter Yield
Charger Yield
EPS Yield
Load Consume
System RunTime
Error Logs
SN
Wifi SN
Machine Type
Inverter DSP1
Manager ARM
Internal Code
Date Time
Advanced
Language
Ethernet
need password
On-grid
User-define
Battery
Reset
Safety
Power Factor
Grid
Export Control
Remote Control
Self Test
Charger
EPS
Reset Inv Energy
Reset Meter Energy
Reset Load
Factory Reset
Config Guide
Work Mode
Relay Control
New Password
Reset Errorlog
8.2 Menu Structure
All advance setting can only be set
by the technician or the installer with
the installer password.
Grid Service
Phase Power Balance
Indicator
LED
Function
Button
Down button: Move cursor to downside or decrease value.
ESC button: Return from current interface or function.
OK button: Confirm the selection.
Up button: Move cursor to upside or increase value.
LCD
Screen
Display the information of the inverter.
Object
A
B
C
D
E
F
Description
G
H
Name
lit in blue: The inverter is in normal status or in EPS mode.
flash in blue: The inverter is in waiting or checking status.
Off: The inverter is in fault status.
lit in green: The battery communication is normal and working.
flash in green: The battery communication is normal and in
idle status.
Off: The battery does not communicate with inverter.
lit in red: The inverter is in fault status.
Off: The inverter has no errors.
Setting Setting
44 45
Feed-in Energy
RegistrationCode

Solax X3-Hybrid Specifications

General

Max. PV Input Voltage	1000 V
IP Protection	IP65
Max. DC Input Voltage	1000 V
Rated Grid Voltage	230 V / 400 V
Grid Frequency	50 Hz / 60 Hz
THD	<3%
Efficiency	97.6%
Power Factor	>0.99
Operating Temperature	-25°C to +60°C
Communication	WiFi, RS485, Ethernet
