Solax X3-Hybrid User Manual

8.3 LCD Operation
● Status
The status function contains five items of the inverter(grid, solar, charger, eps and
Load).
Press up and down to select and press “OK” to confirm the selection, press “ESC”
to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current, output
power, the local consumed power and frequency.
Pout measures the output of inverter;
Pgrid measures power export to or import from grid.
Positive value means the energy feeds into grid, negative value means the
energy used from the grid.
LCD Digital Display
The main interface is the default interface, the inverter will automatically jump to
this interface when the system started up successfully or not operated for a
period of time.
The information of the interface is as below. “Power” means the instant output
power; “Today” means the power generated within the day. “Battery” means the
left capacity of battery energy.
Power 0W
Today 0.0KWh
Battery %
Normal
Status
History
Settings
Menu
Menu interface
The menu interface is a transfer interface for user to get into another interface
to change the setting or getting the information.
-User can get into this interface by pressing “OK” button when LCD displays the
main interface.
-User can select interface by moving the cursor with function button，and press
“OK” to confirm.
Menu
Status
History
Setting
System Switch
About
Grid
Solar
Charger
EPS
Load
Status
Ø
Status
Grid
Solar
Charge
Status
Ua 0.0V
Ia 0.0A
PaOut 0W
Grid
b) Solar
This status shows the real time PV condition of the system, such as input
voltage, current and power situation of each PV input.
U1 600.0V
I1 7.0A
P1 4200W
Solar
46 47
Setting Setting

Solax X3-Hybrid Specifications

General

Max. PV Input Voltage	1000 V
IP Protection	IP65
Max. DC Input Voltage	1000 V
Rated Grid Voltage	230 V / 400 V
Grid Frequency	50 Hz / 60 Hz
THD	<3%
Efficiency	97.6%
Power Factor	>0.99
Operating Temperature	-25°C to +60°C
Communication	WiFi, RS485, Ethernet
