SOLE E95 - Parts List

E95 ELLIPTICAL
27
PARTS LIST
Key
Part Description
Q’ty
1
Main Frame
1
2
Incline Rail Assembly
1
3
Console Holder Assembly
1
4
Cross Bar
2
5
Bushing Housing, Pedal Arm
2
6
Pedal Arm (L)
1
7
Pedal Arm (R)
1
8
Pedal Bar Assembly (L)
1
9
Pedal Bar Assembly (R)
1
10
Lower Handlebar (L)
1
11
Lower Handlebar (R)
1
12
Console Mast
1
13
Idler Bracket
1
14
Crank Axle
1
15
Handpulse Assembly (L)
1
16
Handpulse Assembly (R)
1
17
Rear Rail Assembly
1
18
Joint
1
19
Top Handlebar (L)
1
20
Top Handlebar (R)
1
21
Adjustable Pedal
2
22
Pedal Adjustment Assembly
2
23
Cover Holder(B)
2
24
Controller Fixing Plate
1
25
Fixing Axle
4
26
Ø38 × Ø8.5 × 4T_Flat Washer
2
27
Rod End Sleeve
3
28
Axle
2
29
Adjusting Plate
4
30
Aluminum Rail
4
31
6005_Bearing
5
32
6005-2RSB10+2M5_Bearing
1
33
6003_Bearing
4
34
6203_Bearing
2
35
M12 × P1.75_Rod End Bearing
2
36
Drive Belt
1
37
Flywheel
1
38
Magnet
1
39
Steel Cable
1
40
Handgrip Resistance Label (INCLINE)
1
41
Handgrip Resistance Label (LEVEL)
1
42
Pedal Adjustment Knob
2
45
Console Assembly
1
45-01
Console Top Cover
1
45-02
Console Bottom Cover
1
