40
User Manual
MHT-4~20K series
Figure 5-22
5.5.4 Installing the COM Connector
①
Remove the waterproof lid from the COM terminal.
②

an audible click.
Figure 5-23
Clic
k
2
.
5
+
/
-
0
.
1
N
·m
⑤
Fasten the swivel nut.

