SOLINTEG INTEG M MHT-10K-40 - AC Connection

30
User Manual
MHT-4~20K series
※ 5.2 AC Connection
5.2.1 AC Side Requirements
①


②


③



④


NOTICE
A three-phase AC breaker needs to be installed on the AC side of the MHT-4~20K. To en-
sure that the MHT-4~20K can safely disconnect itself from the power grid when an excep-


The allowable AC cable of wire diameter and cross-sectional area for Solinteg MHT-4~20K

Figure 5-4
Wire󶀅Diameter
13~18mm
Cross-sectional󶀅
Area
2.5~10mm
2
Determine whether an AC circuit breaker with greater overcurrent

NOTICE
