Award BIOS Setup 31
ROM PCI/ISA BIOS
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
PNP OS Installed : No
Resources Controlled By : Manual
Reset Configuration Data : Disabled
ACPI I/O Device Node : Enabled
IRQ-3 assigned to : Legacy ISA
IRQ-4 assigned to : Legacy ISA
IRQ-5 assigned to : PCI/ISA PnP
IRQ-7 assigned to : PCI/ISA PnP
IRQ-9 assigned to : PCI/ISA PnP
IRQ-10 assigned to : PCI/ISA PnP
IRQ-11 assigned to : PCI/ISA PnP
IRQ-12 assigned to : PCI/ISA PnP
IRQ-14 assigned to : PCI/ISA PnP
IRQ-15 assigned to : PCI/ISA PnP
DMA-0 assigned to : PCI/ISA PnP
DMA-1 assigned to : PCI/ISA PnP
DMA-3 assigned to : PCI/ISA PnP
DMA-5 assigned to : PCI/ISA PnP
DMA-6 assigned to : PCI/ISA PnP
DMA-7 assigned to : PCI/ISA PnP
CPU to PCI Write Buffer : Enabled
PCI Dynamic Bursting : Enabled
PCI Master 0 WS Write : Enabled
PCI Delay Transaction : Disabled
PCI Master Read Prefetch : Disabled
PCI#2 Access #1 Retry : Disabled
AGP Master 1 WS Write : Enabled
AGP Master 1 WS Read : Disabled
PCI IRQ Actived By : Level
Assign IRQ For USB : Enabled
Assign IRQ For VGA : Enabled
ESC : Quit ↑ ↓ → ←: Select Item
F1 : Help PU/PD/+/– : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
2. Use one of the arrow keys to move between options and
modify the selected options by using PgUp/PgDn/+/Ð
keys.
A short description of screen options follows:
PNP OS Installed Yes: OS supports Plug and Play
function.
No (default): OS doesnÕt support
Plug and Play function.
Note: BIOS will automatically
disable all PnP resources
except the boot device card
when select Yes on Non-PnP
OS.
Resources
Controlled By
Choose Manual (default) or Auto.
The BIOS checks the IRQ/DMA
channel number on the ISA and PCI
card manually if chose Manual and
the IRQ/DMA channel number will
be checked automatically if choose
Auto.
