67EV1
29
Resource Controlled
By
Choose Manual (default) or Auto. The BIOS checks
the IRQ / DMA channel number on the ISA and PCI
card manually if you choose Manual and the IRQ /
DMA channel number will be checked automatically
if you choose Auto.
Reset Configuration
Data
Choose Enabled or Disabled (default). Disabled re-
tains PnP configuration data in BIOS and Enabled
resets the PnP configuration data in BIOS.
IRQ-x assigned to /
DMA-x assigned to
Legacy ISA: Manually assigns IRQ / DMA to device.
PCI / ISA PnP: BIOS automatically assigns IRQ / DMA
to device.
PNP OS Installed Yes: OS supports Plug and Play function.
No (default): OS doesn’t support Plug and Play
function.
NOTE: BIOS will automatically disable all PnP resources except
the boot device card when you select Yes on Non-PnP
operating system.
Assign IRQ for USB Enabled (default): Add one IRQ to USB controller.
Disabled: Remove IRQ from USB controller. The sys-
tem will have extra IRQ for other devices but the USB
controller will still not be disabled. (only IRQ was
removed)
Assign IRQ for VGA Enabled (default): Add one IRQ to VGA controller.
Disabled: Remove IRQ from USB controller. The sys-
tem will have extra IRQ for other devices but the VGA
controller will still not be disabled. (only IRQ was
removed)
3. Press <ESC> to return to the Main Menu when you finish setting up all
items.
