67EV1
33
ROM PCI/ISA BIOS
INTEGRATED PERPHERALS
AWARD SOFTWARE, INC.
OnChip IDE Channel0 : Enabled
OnChip IDE Channel1 : Enabled
IDE Prefetch Mode : Enabled
Primary Master PIO : Auto
Primary Slave PIO : Auto
Secondary Master PIO : Auto
Secondary Slave PIO : Auto
Primary Master UDMA : Auto
Primary Slave UDMA : Auto
Secondary MasterUDMA : Auto
Secondary Slave UDMA : Auto
Init Display First : PCI Slot
KBC input clock : 8 MHz
Onboard FDC Controller : Enabled
Onboard Serial Port 1 : 3F8/IRQ4
Onboard Serial Port 2 : 2F8/IRQ3
UART Mode Select :
UART2 Duplex Mode : Half
RxD, TxD Active : Lo, Lo
IR Transmission delay : Disabled
Onboard Parallel Port : 378/IRQ7
Parallel Port Mode : ECP/EPP
ECP Mode Use DMA : 3
EPP Mode Select : EPP1.7
POWER ON Function :
KB Power ON Password: Enter
Hot Key Power On : Ctrl - F1
Esc: Quit
F1 : Help
F5 : Old Value
F7 : Load Setup Defaults
PU/PD/+/- : Modify
(Shift) F2 : Color
: Select Item
3-8 INTEGRATED PERIPHERALS
• INTEGRATED PERIPHERALS option allows you to get some informations
inside your system when it is working.
Run the INTEGRATED PERIPHERALS as following:
1. Choose “INTEGRATED PERIPHERALS” from the Main Menu and a screen
with a list of option will appear:
2. Use one of the arrow keys to move between options and modify the se-
lected options by using PgUp / PgDn / + / - keys. An explanation of the
<F> keys follows:
<F1>: “Help” gives oions available for each item.
<Shift> + <F2>: Change color.
<F5>: Get the previous values. These values are the values with which the
user started in the current session.
<F6>: Load all options with the BIOS default values.
<F7>: Load all options with the Setup default values.
