67EV1
28
ROM PCI/ISA BIOS
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
PNP OS Installed : No
Resources Controlled By : Auto
Reset Configuration Data : Disabled
IRQ-3 assigned to : PCI/ISA PnP
IRQ-4 assigned to : PCI/ISA PnP
IRQ-5 assigned to : PCI/ISA PnP
IRQ-7 assigned to : PCI/ISA PnP
IRQ-9 assigned to : PCI/ISA PnP
IRQ-10 assigned to : PCI/ISA PnP
IRQ-11 assigned to : PCI/ISA PnP
IRQ-12 assigned to : PCI/ISA PnP
IRQ-14 assigned to : PCI/ISA PnP
IRQ-15 assigned to : PCI/ISA PnP
DMA-0 assigned to : PCI/ISA PnP
DMA-1 assigned to : PCI/ISA PnP
DMA-3 assigned to : PCI/ISA PnP
DMA-5 assigned to : PCI/ISA PnP
DMA-6 assigned to : PCI/ISA PnP
DMA-7 assigned to : PCI/ISA PnP
CPU to PCI Write Buffer : Enabled
PCI Dynamic Bursting : Enabled
PCI Master 0 WS Write : Enabled
PCI Delay Transaction : Enabled
PCI#2 Access #1 Retry : Disabled
AGP Master 1 WS Write : Disabled
AGP Master 1 WS Read : Disabled
PCI IRQ Actived By : Level
Assign IRQ For USB : Enabled
Assign IRQ For VGA : Enabled
Esc : Quit
F1 : Help
F5 : Old Value
F7 : Load Setup Defaults
PU/PD/+/- : Modify
(Shift) F2 : Color
: Select Item
3-5 PNP / PCI CONFIGURATION SETUP
• PNP/PCI CONFIGURATION SETUP allows you to set the system’s power
saving functions.
Run the PNP/PCI CONFIGURATION SETUP as following:
1. Choose “PNP/PCI CONFIGURATION SETUP” from the Main Menu and a
screen with a list of option will appear:
2. Use one of the arrow keys to move between options and modify the se-
lected options by using PgUp / PgDn / + / - keys. An explanation of the
<F> keys follows:
<F1>: “Help” gives oions available for each item.
<Shift> + <F2>: Change color.
<F5>: Get the previous values. These values are the values with which the
user started in the current session.
<F6>: Load all options with the BIOS default values.
<F7>: Load all options with the Setup default values.
To Next Page
