17
OPEN
CLOSE
CLOSE
Original document - Mi-503 EN Edition: 2022-06
Fig.3-7 Pneumatic actuator type A with two cylinders and schematic drawing of the to-connect air pipes
(single acting - spring to close A-SC)
The ports ā4 / closeā are equipped with silencers
3.5 Accessories
Actuator type A can be equipped with diverse accessories, e.g. valve positioners,
position limit switches and solenoid valves. Please observe the assembly
instructions for each component.
