A 32 - DA - H - D50 - F14
1 2 3 4 5 6
Edition: 2022-06 Original document - Mi-503 EN
7 Product key
1
Low air supply design
Tab.7-1 Description product key
1 Type of actuator 4 Option
2
Acuator size acc. to the selection table E = ATEX design
3 Function H = High temperature design
DA = Double-acting actuator NM = Emergency operation
SC = Single-acting actuator (spring to close) LDC = Locking device (closed position)
SO = Single-acting actuator (spring to open) V = Larger air connections
SCL = Single-acting actuator (spring to close)
1
X = Special design
SOL = Single-acting actuator (spring to open)
1
B = Bronze bushing in lever
5 Shaft diameter
6 Mounting pattern for valve attachment acc. to ISO 5211
