SOMFY 9028474 - FASTENING THE CONNECTIVITY MODULE ON THE BACK OF THE MONITOR

24
FASTENING THE CONNECTIVITY MODULE ON THE BACK OF THE MONITOR:
• Position the connectivity module on the back of the monitor, as per the marks shown below (A).
• Slide the connectivity module up to the stop block, applying constant pressure (B).
• Make sure that there are no cables protruding from the connectivity module.
V®350 monitor
A B
A B
A B
Stop block
V®500 monitor
A B
A B
A B
Stop block
V®500 PRO io monitor
A B
A B
A B
Stop block
