14
STEP
4
CENTER-MOUNT INSTALLATION NOTE Skip this step if performing an end-mount installation.
CAUTION Headrail edges may be sharp, so take care when working with it.
4a. Carefully slide the tilt rod out of one tilt tumbler to expose center of the headrail and to make room for insertion of the motor.
4b. Carefully position the motor in the headrail between the two tilt tumblers.
HELPFUL TIP: Inserting the motor (with one headrail adaptor attached) on an angle will help make this process easier. Then attach the
second headrail adaptor onto the other side of the motor. Make sure that both adaptors are securing the motor firmly within the headrail.
