13
STEP
3
END-MOUNT INSTALLATION NOTE Skip this step if performing a center-mount installation.
CAUTION Headrail edges may be sharp, so take care when working with it.
3a. Carefully slide the motor into the headrail from one end. Then slide the tilt rod into the tilt rod adaptor. NOTE: If the tilt rod doesn’t
extend through the motor, reverse it.
3b. If previously removed, re-install the C-Clip or retaining device to the tilt rod.
3c. Replace the end caps.
