8
STEP
2
PREPARE FOR MOTOR INSTALLATION
IMPORTANT Before you install the Clever motor, it is important to make certain that it and the headrail adaptors
will fit securely in the headrail. Remove the headrail adaptors included in the packaging and make certain that
at least one pair fits properly in the headrail – not too loose or too tight. If the fit isn’t right, please contact Somfy at
1-800-822-7468 and
do not proceed with the installation.
2a. Select the correct pair of headrail adaptors (B) that best match the size & shape of your blind’s headrail. Set them aside.
B
B1 B2 B3
2b. Select the tilt rod adaptor (C) that best matches your blind’s tilt rod. NOTE: Only one tilt rod adaptor is required. Set it aside.
C
C1 C2 C3 C4 C5 C6 C7
