S201 AFM
1 - GENERAL INFORMATION
1.5 - AIRCRAFT DESCRIPTION
AND DIMENSIONS
27/06/2019
SONAIR-S2-D-MAN-006
Page : 1-9
Rev. : A
EMPENNAGE
Metric
Imperial
Horizontal stabilizer span:
2.822 m
9 ft 3 inch.
Horizontal stabilizer surface area:
0.96 m
2
10 ft
2
Elevator surface area:
1.02 m
2
11 ft
2
Horizontal stabilizer angle of
incidence
- 1.45
o
Vertical stabilizer span:
1.47 m
16 ft
Vertical stabilizer surface area:
0.53 m
2
6 ft
2
Rudder surface area:
0.59 m
2
6 ft
2
LANDING GEAR
Metric
Imperial
Wheel track:
1.92 m
6ft 4 inch.
Wheel base:
1.54m
5ft 1 inch.
Brakes:
Hydraulic.
Main gear tyres pressure :
3.4 bar
49 psi
Nose gear tyre pressure :
2.2 bar
29 psi
