7.4.6 FLAP CONTROL
Wing flaps are electrically controlled by a four-position lever located on the
instrument panel (refer to paragraph 7.5). A mechanical flap indicator located
next to the lever shows the current flap position.
The flap motor is located in the cabin centre console. The two wing flaps are
interconnected via a torque tube, which is driven at a single point by the flap
motor. In case of a failure in the linkage system, this prevents the flaps from
being deployed to asymmetrical positions.
See section 7.5 for the location of the flap lever and indicator location on the
instrument panel.
