S201 AFM
7 - AIRPLANE AND SYSTEMS
DESCRIPTION
7.4 - FLIGHT CONTROLS
27/06/2019
SONAIR-S2-D-MAN-006
Page : 7-9
Rev. : A
Following flaps settings are defined on the S201:
Selector
Position
Degrees flap
deflection
UP
0°
T/O
10°
APP
20°
LD
30°
The flap controller is powered from the main bus. The flap controller in turn
powers the flap motor, via a circuit breaker located on the instrument panel
(refer to paragraph 7.5). The Flap control necessitates a power up time of 11
sec. The Flap cannot be actuated during that period of time.
WARNING
The flap system becomes non-operational with loss of power to the main
bus. The main bus is powered by the Master Switch.
