7.6 WARNING, CAUTION AND STATUS LIGHTS
Warning lights are provided to announce hazardous system operation to the
pilot. They are located at the top centre of the instrument panel as described
below:
All warning lights except the EMS RAL can be dimmed by turning the light
housing and can be tested by pushing on them.
The EMS RAL features a self-test at start-up of the EMS display.
Refer to sections 3.10.3, 3.3.13 and 3.3.14 for information on causes and
adequate action in case of warning light illumination.
EMS Remote
Alert LED
ALT 1 Charge
caution light
ALT 2 Charge
caution light
TCU caution
light
TCU warning
light
