To actuate the brakes using pedals, apply pressure on the top of each pedals
using your toes. This will rotate the pedals around their central axis, and
compress the two brakes cylinders.
To activate the Parking Brake, apply brakes as described above and pull the Park
Brake valve rearward, keeping the pedals pushed until the valve has reached its
rearward stop. To release the Parking Brake, apply pressure on pedals and move
the valve forward in the same way.
Pressure on both pedals should always be applied when engaging and
disengaging the parking brake valve.
7.12.3 TYRES
Tyre approved types :
Nose Landing Gear Tyre : Michelin Aviator 5.00-5/10/120
Main Landing Gear Tyres : Michelin Air 380X150/15X6.00-5/6/120
Tyre inflating pressure :
Nose Landing Gear Tyre : 2.2 bar (39 psi) with a tolerance of +-0.2 bar;
Main Landing Gear Tyres : 3.4 bar (49 psi) with a tolerance of +- 0.2 bar.
